Decoding the 2015 Ram 1500 Wiring Diagram for Trailer Brake Installs
Installing an aftermarket trailer brake controller in a 4th-generation Ram requires far more than simply splicing a few wires together. The 2015 Ram 1500 wiring diagram reveals a highly complex, multiplexed electrical architecture managed by the Totally Integrated Power Module (TIPM) and the CAN C / CAN IHS bus networks. Unlike older trucks that relied on simple mechanical relays and point-to-point 12V routing, the 2015 Ram utilizes solid-state switching, pulse-width modulation (PWM), and active current monitoring to manage trailer lighting and braking circuits.
This practical how-to guide will walk you through the precise steps of wiring an aftermarket proportional brake controller (such as a Tekonsha Prodigy P3 or Redarc Tow-Pro Elite) in a 2015 Ram 1500. We will cover the critical under-dash pigtail identification, the dangers of tapping the wrong stoplight circuit, firewall routing techniques, and TIPM troubleshooting protocols.
The PWM Stoplight Switch Dilemma: A Critical Warning
Before cutting or stripping a single wire, you must understand a major pitfall specific to the 2013-2018 Ram 1500 platform. In older vehicles, installers would tap directly into the stoplight switch at the brake pedal arm to trigger the brake controller's red input wire. Do not do this on a 2015 Ram 1500.
The 2015 Ram uses a Hall-effect, Pulse-Width Modulated (PWM) stoplight switch. The TIPM reads the duty cycle of this signal to determine brake pedal application and modulate the rear taillights accordingly. If you tap this low-voltage PWM circuit with a standard 12V brake controller input, you will backfeed voltage into the TIPM logic board. This will instantly trigger a "Trailer Wiring Fault" or "Stoplamp Switch Fault" on the EVIC (Electronic Vehicle Information Center) dashboard display, and can permanently damage the TIPM's internal microprocessors.
The Solution: You must tap the Center High Mount Stop Lamp (CHMSL) circuit at the rear of the truck, or use a dedicated 2-wire stoplight isolation relay module. This guide focuses on the CHMSL tap method, which provides a clean, switched 12V signal without interfering with the CAN bus logic.
Step-by-Step Brake Controller Wiring Installation
Step 1: Locating the Under-Dash Blunt-Cut Pigtail
If your 2015 Ram 1500 was ordered with the factory Class IV Tow Package, Mopar pre-installed a blunt-cut 4-wire pigtail under the driver's side dash. To locate it:
- Remove the lower kick panel beneath the steering column by removing the two 7mm hex-head screws and releasing the plastic tension clips.
- Look up and to the left of the steering shaft, near the parking brake pedal assembly.
- You are looking for a bundle of four wires wrapped in black corrugated loom and terminated with a grey Molex connector or blunt-cut and taped.
If your truck did not have the factory tow package, this pigtail will be absent. You will need to route a new 4-conductor cable from the rear 7-way connector, through the firewall, to the dash. (See Step 3 for firewall routing).
Step 2: Understanding the Mopar Pigtail Wire Colors
If you have the factory under-dash pigtail, the 2015 Ram 1500 wiring diagram dictates the following OEM color codes for the tow module interface:
- Black (12 AWG): 12V Constant Battery Feed. This provides the main power to the brake controller. It is fed through a 30-amp fuse in the TIPM (Fuse J09 or similar, depending on build date).
- White (10 AWG): Chassis Ground. This must be terminated to a clean, unpainted metal surface under the dash. Do not rely on the controller's internal ground alone; a poor ground here causes erratic proportional braking.
- Blue (12 AWG): Trailer Brake Output. This wire travels from the dash, back through the TIPM, and out to Pin 2 on the rear 7-way RV blade connector.
- Red or Light Blue/White (14 AWG): Stoplight Switch Input. This is the trigger wire that tells the controller you are pressing the brake pedal.
Step 3: Firewall Routing (If Pigtail is Missing)
If you must run your own wires from the rear 7-way to the dash, you need to pass through the firewall safely.
- Locate the main firewall wiring grommet on the driver's side, directly behind the parking brake pedal bracket.
- Use a fiberglass fish tape or a stiff piece of 14 AWG wire wrapped in electrical tape to pierce the outer lip of the rubber grommet. Never pierce the center where the factory harness sits, as you risk damaging the CAN C bus wires.
- Pull a 4-conductor, 12 AWG shielded trailer cable through the grommet into the engine bay, then route it along the driver's side frame rail to the rear bumper.
- At the rear 7-way connector, use adhesive-lined heat shrink butt connectors (12-10 AWG) to tap into the Blue (Brake Output), Black (12V Aux), and White (Ground) wires.
Step 4: Tapping the CHMSL Circuit for the Stoplight Trigger
To get a safe, non-PWM stoplight signal for the controller's Red trigger wire:
- Access the rear taillight junction block or the CHMSL wiring harness near the top center of the rear cab window.
- Identify the CHMSL feed wire. According to the Mopar TechAuthority schematics, this is typically a White/Tan or Dark Green/Red wire (verify with a multimeter: it should read 0V with brakes off, and a solid 12V with brakes applied).
- Use a Posi-Tap connector or a high-quality solder-and-heat-shrink splice to connect your brake controller's Red trigger wire to this CHMSL circuit.
- Run this trigger wire up the driver's side frame rail, through your firewall grommet, and connect it to the Red/Light Blue wire on your under-dash pigtail.
Technical Reference Tables
SAE J560 / J2807 Standard 7-Way RV Blade Pinout
When verifying your connections at the rear bumper, ensure your 7-way plug matches the SAE J2807 and J560 standards. Miswiring the trailer side will cause TIPM lockouts.
| Pin Position | Function | OEM Wire Color (Ram 1500) | Wire Gauge (AWG) |
|---|---|---|---|
| 1 (Top Left) | Tail / Running Lamps | Brown | 14 AWG |
| 2 (Top Right) | Trailer Brake Output | Dark Blue | 12 AWG |
| 3 (Bottom Left) | Ground (Chassis) | White | 10 AWG |
| 4 (Center) | 12V Auxiliary / Battery Feed | Black | 12 AWG |
| 5 (Bottom Right) | Right Turn / Stop | Green | 14 AWG |
| 6 (Bottom Center) | Left Turn / Stop | Red | 14 AWG |
| 7 (Top Center) | Reverse Lamps / Aux | Purple | 14 AWG |
Recommended Splicing & Termination Materials
| Material | Application | Why It Is Required |
|---|---|---|
| Adhesive-Lined Heat Shrink | All exterior / underbody splices | Prevents copper oxidation and green corrosion, which alters resistance and tricks the TIPM current sensors. |
| Posi-Tap Connectors | CHMSL Stoplight Trigger Tap | Pierces the wire without severing the internal copper strands, maintaining structural integrity for low-current logic signals. |
| Ring Terminals (12-10 AWG) | White Ground Wire to Chassis | Ensures maximum surface area contact. Sand the chassis to bare metal and apply dielectric grease over the top to prevent rust. |
Troubleshooting TIPM Lockouts and CAN Bus Faults
The TIPM in the 2015 Ram 1500 actively monitors the resistance and current draw of all trailer circuits. If you encounter issues after your installation, consult this diagnostic tree:
Symptom: "Trailer Wiring Fault" Message on Dash
- Cause 1: LED Trailer Lights. LEDs draw significantly less current than incandescent bulbs. The TIPM interprets this low current draw as a "burnt out bulb" and shuts down the circuit to prevent a short. Fix: Install a Mopar LED Trailer Tow Module adapter or solder 10-ohm, 50-watt load resistors in parallel with the trailer's turn signal circuits.
- Cause 2: Corroded 7-Way Ground. If the 10 AWG White ground wire at the bumper is corroded, current seeks an alternate path (backfeeding through the turn signal bulbs). Fix: Clean the 7-way ground pin and the truck's chassis grounding point near the rear bumper.
Symptom: Brake Controller Powers On, But No Output to Trailer
- Cause: The TIPM requires a "dealer flash" or EVIC configuration to enable the trailer brake output relay if the truck was not originally equipped with the factory brake controller module.
- Fix: Go to the EVIC menu (Settings -> Trailer Tow). If "Trailer Brake Gain" is missing, the TIPM must be flashed with the latest sales code for the Trailer Brake Module via an OBDII tool like an AlfaOBD or a dealer visit. Alternatively, bypass the TIPM entirely by running a dedicated 12 AWG Blue wire directly from the controller's output pin, through the firewall, straight to Pin 2 on the rear 7-way connector.
Symptom: Controller Displays "SH" (Short) or "OL" (Open Load)
- Cause: A break in the Blue output wire or a short to ground.
- Fix: Use a digital multimeter to test continuity from the controller's Blue output wire to Pin 2 on the 7-way connector. If using the factory under-dash pigtail, ensure the connection between the pigtail's Blue wire and the controller's Blue wire is secure. The etrailer.com Wiring FAQ highly recommends using a dedicated circuit tester (not a standard test light, which can draw too much current and blow the TIPM solid-state relay) to verify the Blue wire's path.
Final Verification and Safety Checks
Once all connections are soldered, shrunk, and loomed, perform a static test before hitting the road. Connect a trailer with known-good incandescent brakes. Turn the ignition to the "RUN" position (engine off). Manually slide the brake controller's override lever. You should hear a distinct "click" from the trailer's brake magnets, and the controller should display the amperage draw (typically 12-15 amps for a dual-axle trailer). Finally, verify that the truck's EVIC does not display any warning messages. By respecting the complexities of the 2015 Ram 1500 wiring diagram and avoiding the PWM stoplight trap, your towing setup will be safe, reliable, and fault-free.
